Product Advantage
1.Efficient Heating & Temperature Control
Electric heating ensures rapid and uniform heat distribution, with precise digital temperature control (±2°C) for consistent product quality.
2.Energy Saving & Cost Effective
High thermal efficiency minimizes heat loss, significantly reducing electricity consumption and operational expenses.
3.Safe & Durable Design
The double-layered stainless steel structure prevents surface overheating, enhancing operator safety. Robust construction ensures long-term reliability.
4.Easy to Operate & Maintain
User-friendly interface with optional stirring and tilting functions. Smooth inner surface allows quick cleaning and low maintenance.
5.Versatile Application
Ideal for food processing, pharmaceuticals, chemicals, and daily chemicals—suitable for cooking, mixing, dissolving, and sterilizing.
Technical Parameters
Heating Method: Electric heating elements, power 9‒36 kW
Jacket Pressure: Normal pressure / low-pressure optional
Material: 304stainless steel (inner & jacket)
Control: Digital PID temperature controller, PLC optional
Ports: Inlet/outlet, drain, safety valve, thermometer port
Product Uses
This electric heating jacketed kettle is widely used in industries requiring precise thermal processing. In the food sector, it is ideal for cooking, boiling, stewing, sauce preparation, candy making, and jam production. In pharmaceuticals and biotechnology, it serves for mixing, dissolution, sterilization, and reaction processes. The chemical and daily chemical industries utilize it for heating, emulsifying, and synthesizing products.
Product Operate Guide
Preparation: Clean the kettle and ensure valves are closed.
Loading: Add materials via the inlet port.
Heating: Set the desired temperature via the PID controller and start heating.
Discharge: Open the bottom valve to unload the product.
Cleaning: Rinse and sanitize after use. Always follow safety guidelines.
FAQ
Q: What temperature range does it support?
A: Up to 300°C with ±2‑5°C accuracy.
Q: Is stirring function available?
A: Yes, optional variable-speed agitator (0‑63 rpm).
Q: What safety features are included?
A: Overheat protection, safety valves, and insulated jacket.
Q: How is cleaning performed?
A: Smooth stainless steel surface allows easy manual or CIP cleaning.
