Product Advantage
High Output: Continuous automation enables large-scale production with stable capacity.
Consistent Quality: Uniform slicing, precise frying control, and even seasoning ensure product consistency.
Oil Efficiency: Advanced frying and deoiling systems extend oil life and reduce waste.
Flexible Seasoning: Supports a variety of seasonings and coatings for diverse flavor profiles.
Hygienic & Safe: Full stainless steel construction, easy to clean, meets food safety standards.
Energy Saving: Optimized heat exchange and insulation lower energy consumption.
Technical Parameters
Capacity: 100‒2000 kg/h
Slice Thickness: 0.8‒2.5 mm (adjustable)
Frying Temperature: 160‒190°C
Oil Type: Vegetable oil, high oleic options supported
Material: 304 stainless steel
Power: 80‒300 kW
Control: PLC + touchscreen, frying time/temp adjustable
Options: Multi-zone frying, oil filtration, seasoning drum, nitrogen flushing packaging interface
Product Uses
This line is widely used by snack food manufacturers, potato processing plants, and large-scale food producers to make branded or private-label potato chips for retail, food service, and export markets. It is also suitable for specialty snack companies producing vegetable chips, root vegetable chips, and extruded snacks with similar frying and seasoning processes.
Product Operate Guide
1.Preparation: Inspect slicer, fryer, and seasoning system; preheat oil to set temperature.
2.Feeding: Load washed potatoes into the slicer hopper.
3.Processing: Start slicing, frying, de-oiling, and seasoning in sequence.
4.Monitoring: Adjust slice thickness, fry time/temp, seasoning rate for quality control.
5.Packaging: Transfer chips to packaging line (nitrogen flushing optional).
6.Cleaning & Shutdown: Clean all contact surfaces, filter oil, and perform routine maintenance. Follow safety protocols.
FAQ
Q: Can it make other vegetable chips?
A: Yes, with adjustments for sweet potato, beet, carrot, or parsnip chips.
Q: How is oil quality maintained?
A: Continuous filtration, temperature control, and oil replenishment systems ensure stability.
Q: Is seasoning adjustable?
A: Yes, seasoning drum speed and powder feed rate are adjustable for uniform coverage.
Q: What packaging is supported?
A: Can integrate with vertical form-fill-seal machines, often with nitrogen flushing for freshness.
